Type 1000 - T1000 E/P Transducer
The Bellofram Precision Controls Type 1000 E/P Transducer is a compact voltage-to-pressure converter that turns a 0-5 V control signal into proportional pneumatic pressure for industrial automation. This configuration supports a 0-30 PSIG output range, uses an integral pneumatic volume booster for flow up to 12 SCFM, and operates with supply pressure up to 100 psi. Its small, lightweight design and pipe, panel, bracket, or DIN-rail mounting options make it well suited to valve actuators, positioners, dampers, air cylinders, HVAC equipment, energy-management systems, and process instrumentation.
Features:
- High Flow, Low Waste: Features a built-in pneumatic volume booster delivering up to 12 SCFM (339 SLPM) while maintaining low air consumption for high efficiency.
- Flexible Installation: A small, lightweight design that mounts at any angle, making it ideal for space-constrained skids and complex piping layouts.
- Field Versatility: Fully field reversible with convenient external span and zero adjustments for fast calibration and maintenance.
- Rugged Configurations: Engineered for reliability with low supply pressure sensitivity; available in NEMA 4X, Intrinsically Safe, and Explosion Proof models.
- Actuation & Motion: Precise control for valve actuators, air cylinders, dampers, louvers, and clutches/brakes.
- Process Instrumentation: Trusted in petrochemical processing, paper handling, textile systems, and liquid/gas instrumentation.
- System Integration: Ideal for HVAC systems, energy management, controllers, and split-ranging relays.
Options
Explosion Proof Mounting Kit, Explosion Proof Panel Mounting Kit, DIN Rail Kit, Hirschman Connector Kit (3-prong), Filter Kit, 60 micron, Output Gauges, Dielectric Strength Testing,
Output Port
1/4" NPT
Supply Port
1/4" NPT
Exhaust Port
No
Logic Output
No
Air Consumption
6
Exhaust Capture
No
Measured Outlet
Midrange
Measured Supply
100 psi
Port Size
1/4" NPT,
1/2" NPT
Flow Rate (scfm)
12 scfm
Mounting Options
Pipe, Panel, Bracket or DIN-rail
External Feedback
No
Output Gauge Port
Yes
Input Signal
0-5 VDC
Analog Monitor Output
No
Electrical Port (STD)
1/2" NPT
Operating Temp (⁰C)
-29º to 60º
E/P Supply Requirements
loop-powered
Maximum Accuracy
1%
Current Input Ranges (mA)
n/a
Voltage Input Ranges (DC)
0-5 V
Accuracy (% of span, typ.)
1
Hysterisis (% of span, typ.)
1
Width x Depth x Height (in.)
2 1⁄8" – 2 1⁄8"– 4"
External Span/Zero Adjustment
Yes
Output Pressure Ranges
0-30 PSIG
Maximum Supply Pressure (psi)
100 psi
Minimum Supply Pressure (psi)
3 psig above output
Maximum Supply Pressure
100 PSIG
Electrical Connections (option)
Terminal Block, Din 43650-A
Internal Feedback (closed loop)
No
Repeatability (% of span, typ.)
0.5
Exhaust Capacity (scfm) @ 5 psid
2
Mounting Orientation Insensitivity
Some
Independent Linearity (% of span, typ.)
1
Find Your Part Number
Not sure? Call for help. Phone: 304-387-1200
